4 Data Scales and Units
Code Condition Value/Range Notes
Data Scales
Vmax
Voltage scale × PT Ratio, V
2
Imax
Current scale (2A/10A) × CT Ratio = CT Primary current × 2, A
1, 3
Wiring 4LN3, 3LN3, 3BLN3
Vmax × Imax × 3, W
4
Pmax
Wiring 4LL3, 3LL3, 3BLL3,
3OP2, 3OP3, 3DIR2
Vmax × Imax × 2, W
Fmax Nominal frequency 50 or 60
Hz
100 Hz
+/-1mA
AImin = -AI full scale × 2
AImax = AI full scale × 2
0-20mA AImin = AI zero scale
AImax = AI full scale
4-20mA AImin = AI zero scale
AImax = AI full scale
AImin
AImax
0-1mA AImin = AI zero scale
AImax = AI full scale
Data Units
PT Ratio = 1 0.1 V U1
PT Ratio > 1 1 V
U2 0.01 A
PT Ratio = 1 0.001 kW/kvar/kVA U3
PT Ratio > 1 1 kW/kvar/kVA
1
CT Ratio = CT primary current/CT secondary current
2
The default Voltage scale is 144V (120V +20%). You can change it via the Device Data Scale setup (see Section 3.1) or via
the Device Options setup in PAS.
3
The default Current scale is 2 × CT secondary current (2 × 1A or 2 × 5A depending on the order).
4
Pmax is rounded to whole kilowatts. With PT=1.0, if Pmax is greater than 9,999,000 W, it is truncated to 9,999,000 W.
