81
Address Point ID Description Options/Range Units Type R/W Notes
+5 Record size, words 18 UINT16 R
+6 Request variation 0 UINT16 R
+7 Reserved 0 UINT16 R
63160-63799 PQ Log Records
+0 Record status F5 INT16 R
+1 Record sequence number 0-65535 UINT16 R
+2, 3 Start time, seconds since 1/1/1970 F1 sec UINT32 R
+4, 5 Start time, fractional seconds in µsec µsec UINT32 R
+6, 7 End time, seconds since 1/1/1970 F1 sec UINT32 R
+8, 9 End time, fractional seconds in µsec µsec UINT32 R
+10 PQ event type F22 UINT16 R
+11 PQ event number 1-65535 UINT16 R
+12 Point ID (generic) See Generic Data in Section 3.4 UINT16 R
+13 Reserved 0 UINT16 R
+14, 15 Value reference (base), primary units See Generic Data in Section 3.4 INT32 R
+16, 17 Value magnitude, primary units See Generic Data in Section 3.4 INT32 R
63160-63179 Record #1
...
63430-63447 Record #16
Fault Log Response Block
63152-63159 Block Heading V24.3.1 and higher
+0 Last file function 1, 3, 5, 11 UINT16 R
+1 File ID 27 UINT16 R
+2 Section number 0 UINT16 R
+3 Section channel ID 0 UINT16 R
+4 Number of records in the block 1-32 UINT16 R
+5 Record size, words 22 UINT16 R
+6 Request variation 0 UINT16 R
+7 Not used 0 UINT16 R
63160-64183 Fault Log Records
+0 Record status F5 INT16 R
+1 Record sequence number 0-65535 UINT16 R
+2, 3 Start time, seconds since 1/1/1970 F1 sec UINT32 R
+4, 5 Start time, fractional seconds in µsec µsec UINT32 R
+6, 7 End time, seconds since 1/1/1970 F1 sec UINT32 R
+8, 9 End time, fractional seconds in µsec µsec UINT32 R
+10 Fault event type F22 UINT16 R
+11 Fault event number 1-65535 UINT16 R
+12 Current phase point ID (generic) 0-65535 UINT16 R
+13 Volts phase point ID (generic) 0-65535 UINT16 R
+14, 15 Current reference (base), primary units See Generic Data in Section 3.4 U4 INT32 R
+16, 17 Current magnitude, primary units See Generic Data in Section 3.4 U4 INT32 R
+18, 19 Volts reference (base), primary units See Generic Data in Section 3.4 U1 INT32 R
