Satec PM174 User Manual

28
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
5504-5553 I3 Harmonic Distortion
+0 0x1E00
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1E01
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+49 0x1E31
H50 Harmonic distortion
0-100.00 0.01% UINT16 R
6208-6225 Fundamental Phase Values
5
+0 0x2900 V1/V12 Voltage 0-Vmax U1 UINT16 R
2
+1 0x2901 V2/V23 Voltage 0-Vmax U1 UINT16 R
2
+2 0x2902 V3/V31 Voltage 0-Vmax U1 UINT16 R
2
+3 0x2903 I1 Current 0-Imax U2 UINT16 R
+4 0x2904 I2 Current 0-Imax U2 UINT16 R
+5 0x2905 I3 Current 0-Imax U2 UINT16 R
+6 0x2906 kW L1 -Pmax-Pmax U3 INT16 R
+7 0x2907 kW L2 -Pmax-Pmax U3 INT16 R
+8 0x2908 kW L3 -Pmax-Pmax U3 INT16 R
+9 0x2909 kvar L1 -Pmax-Pmax U3 INT16 R
+10 0x290A kvar L2 -Pmax-Pmax U3 INT16 R
+11 0x290B kvar L3 -Pmax-Pmax U3 INT16 R
+12 0x290C kVA L1 0-Pmax U3 UINT16 R
+13 0x290D kVA L2 0-Pmax U3 UINT16 R
+14 0x290E kVA L3 0-Pmax U3 UINT16 R
+15 0x290F Power factor L1 -1.000-1.000 0.001 INT16 R
+16 0x2910 Power factor L2 -1.000-1.000 0.001 INT16 R
+17 0x2911 Power factor L3 -1.000-1.000 0.001 INT16 R
6240-6251 Flicker
2
+0 0x2980 V1 Pst 0-100.00 0.01 UINT16 R
+1 0x2981 V2 Pst 0-100.00 0.01 UINT16 R
+2 0x2982 V3 Pst 0-100.00 0.01 UINT16 R
+3 0x2983 V1 Plt 0-100.00 0.01 UINT16 R
+4 0x2984 V2 Plt 0-100.00 0.01 UINT16 R
+5 0x2985 V3 Plt 0-100.00 0.01 UINT16 R
6272-6275 Fundamental Total Values
5
+0 0x2A00 Total fundamental kW -Pmax-Pmax U3 INT16 R
+1 0x2A01 Total fundamental kvar -Pmax-Pmax U3 INT16 R
+2 0x2A02 Total fundamental kVA 0-Pmax U3 UINT16 R
+3 0x2A03 Total fundamental PF -1.000-1.000 0.001 INT16 R
6400-6429 Minimum 1-Cycle Phase Values
+0 0x2C00 V1/V12 Voltage 0-Vmax U1 UINT16 R
2
+1 0x2C01 V2/V23 Voltage 0-Vmax U1 UINT16 R
2
+2 0x2C02 V3/V31 Voltage 0-Vmax U1 UINT16 R
2
+3 0x2C03 I1 Current 0-Imax U2 UINT16 R
+4 0x2C04 I2 Current 0-Imax U2 UINT16 R
+5 0x2C05 I3 Current 0-Imax U2 UINT16 R
