Satec PM174 User Manual

29
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
+6-17 0x2C06-
0x2C11
Not used 0 INT16 R
+18 0x2C12 V1/V12 Voltage THD 0-9999 0.1% UINT16 R
2, 5
+19 0x2C13 V2/V23 Voltage THD 0-9999 0.1% UINT16 R
2, 5
+20 0x2C14 V3/V31 Voltage THD 0-999.9 0.1% UINT16 R
2, 5
+21 0x2C15 I1 Current THD 0-999.9 0.1% UINT16 R
5
+22 0x2C16 I2 Current THD 0-999.9 0.1% UINT16 R
5
+23 0x2C17 I3 Current THD 0-999.9 0.1% UINT16 R
5
+24 0x2C18 I1 K-Factor 1.0-999.9 0.1 UINT16 R
5
+25 0x2C19 I2 K-Factor 1.0-999.9 0.1 UINT16 R
5
+26 0x2C1A I3 K-Factor 1.0-999.9 0.1 UINT16 R
5
+27 0x2C1B I1 Current TDD 0-100.0 0.1% UINT16 R
5
+28 0x2C1C I2 Current TDD 0-100.0 0.1% UINT16 R
5
+29 0x2C1D I3 Current TDD 0-100.0 0.1% UINT16 R
5
6464-6467 Minimum 1-Cycle Total Values
+0 0x2D00 Total kW -Pmax-Pmax U3 INT16 R
+1 0x2D01 Total kvar -Pmax-Pmax U3 INT16 R
+2 0x2D02 Total kVA 0-Pmax U3 UINT16 R
+3 0x2D03 Total PF 0-1.000 0.001 UINT16 R Absolute value
6528-6530 Minimum 1-Cycle Auxiliary Values
+0 0x2E00 Not used U2 UINT16 R
+1 0x2E01 In Current 0-Imax U2 UINT16 R
+2 0x2E02 Frequency 0-Fmax 0.01Hz UINT16 R
6912-6941 Maximum 1-Cycle Phase Values
+0 0x3400 V1/V12 Voltage 0-Vmax U1 UINT16 R
2
+1 0x3401 V2/V23 Voltage 0-Vmax U1 UINT16 R
2
+2 0x3402 V3/V31 Voltage 0-Vmax U1 UINT16 R
2
+3 0x3403 I1 Current 0-Imax U2 UINT16 R
+4 0x3404 I2 Current 0-Imax U2 UINT16 R
+5 0x3405 I3 Current 0-Imax U2 UINT16 R
+6-17 0x3406-
0x3411
Not used 0 INT16 R
+18 0x3412 V1 Voltage THD 0-999.9 0.1% UINT16 R
2, 5
+19 0x3413 V2 Voltage THD 0-999.9 0.1% UINT16 R
2, 5
+20 0x3414 V3 Voltage THD 0-999.9 0.1% UINT16 R
2, 5
+21 0x3415 I1 Current THD 0-999.9 0.1% UINT16 R
5
+22 0x3416 I2 Current THD 0-999.9 0.1% UINT16 R
5
+23 0x3417 I3 Current THD 0-999.9 0.1% UINT16 R
5
+24 0x3418 I1 K-Factor 1.0-999.9 0.1 UINT16 R
5
+25 0x3419 I2 K-Factor 1.0-999.9 0.1 UINT16 R
5
+26 0x341A I3 K-Factor 1.0-999.9 0.1 UINT16 R
5
+27 0x341B I1 Current TDD 0-100.0 0.1% UINT16 R
5
+28 0x341C I2 Current TDD 0-100.0 0.1% UINT16 R
5
