Satec PM174 User Manual

30
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
+29 0x341D I3 Current TDD 0-100.0 0.1% UINT16 R
5
6976-6979 Maximum 1-Cycle Total Values
+0 0x3500 Total kW -Pmax-Pmax U3 INT16 R
+1 0x3501 Total kvar -Pmax-Pmax U3 INT16 R
+2 0x3502 Total kVA 0-Pmax U3 UINT16 R
+3 0x3503 Total PF 0-1.000 0.001 UINT16 R Absolute value
7040-7042 Maximum 1-Cycle Auxiliary Values
+0 0x3600 Not used U2 UINT16 R
+1 0x3601 In Current 0-Imax U2 UINT16 R
+2 0x3602 Frequency 0-Fmax 0.01Hz UINT16 R
7104-7120 Maximum Demands
+0 0x3700 V1/V12 Maximum volt demand 0-Vmax U1 UINT16 R
2
+1 0x3701 V2/V23 Maximum volt demand 0-Vmax U1 UINT16 R
2
+2 0x3702 V3/V31 Maximum volt demand 0-Vmax U1 UINT16 R
2
+3 0x3703 I1 Maximum ampere demand 0-Imax U2 UINT16 R
+4 0x3704 I2 Maximum ampere demand 0-Imax U2 UINT16 R
+5 0x3705 I3 Maximum ampere demand 0-Imax U2 UINT16 R
+6 0x3706 Not used UINT16 R
+7 0x3707 Not used UINT16 R
+8 0x3708 Not used UINT16 R
+9 0x3709 Maximum kW import sliding window demand 0-Pmax U3 UINT16 R
+10 0x370A Maximum kvar import sliding window demand 0-Pmax U3 UINT16 R
+11 0x370B Maximum kVA sliding window demand 0-Pmax U3 UINT16 R
+12 0x370C Not used UINT16 R
+13 0x370D Not used UINT16 R
+14 0x370E Not used UINT16 R
+15 0x370F Maximum kW export sliding window demand 0-Pmax U3 UINT16 R
+16 0x3710 Maximum kvar export sliding window demand 0-Pmax U3 UINT16 R
7200-7211 Maximum Harmonic Demands
+0 0x3880 V1/V12 THD demand 0-999.9 0.1% UINT16 R
2
+1 0x3881 V2/V23 THD demand 0-999.9 0.1% UINT16 R
2
+2 0x3882 V3/V31 THD demand 0-999.9 0.1% UINT16 R
2
+3 0x3883 Not used UINT16 R
+4 0x3884 I1 THD demand 0-999.9 0.1% UINT16 R
+5 0x3885 I2 THD demand 0-999.9 0.1% UINT16 R
+6 0x3886 I3 THD demand 0-999.9 0.1% UINT16 R
+7 0x3887 Not used UINT16 R
+8 0x3888 I1 TDD demand 0-100.0 0.1% UINT16 R
+9 0x3889 I2 TDD demand 0-100.0 0.1% UINT16 R
+10 0x388A I3 TDD demand 0-100.0 0.1% UINT16 R
+11 0x388B Not used UINT16 R
7360-7361 Scaled Analog Inputs
+0 0x3B00 Analog input AI1 AI1min-AI1Max UINT16 R
