Satec PM174 User Manual

31
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
+1 0x3B01 Analog input AI2 AI2min-AI2Max UINT16 R
7392-7393 Raw Analog Inputs
+0 0x3B80 Analog input AI1 0-4095 UINT16 R
+1 0x3B81 Analog input AI2 0-4095 UINT16 R
7424-7425 TOU Parameters
+0 0x3C00 Active tariff 0-7 UINT16 R/W
+1 0x3C01 Active profile 0-15:
0-3 = Season 1 Profile #1-4,
4-7 = Season 2 Profile #1-4,
8-11 = Season 3 Profile #1-4,
12-15 = Season 4 Profile #1-4
UINT16 R/W
7456-7457 Scaled Analog Outputs
+0 0x3C80 Analog output AO1 0-4095 UINT16 R/W
+1 0x3C81 Analog output AO2 0-4095 UINT16 R/W
7488-7503 Billing TOU Energy Register #1
+0,1 0x3D00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3D01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x3D07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
7552-7567 Billing TOU Energy Register #2
+0,1 0x3E00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3E01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x3E07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
7616-7631 Billing TOU Energy Register #3
+0,1 0x3F00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3F01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x3F07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
7680-7695 Billing TOU Energy Register #4
+0,1 0x4000
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4001
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4007
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
7744-7759 Billing TOU Energy Register #5
+0,1 0x4100
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4101
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4107
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
7808-7823 Billing TOU Energy Register #6
+0,1 0x4200
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4201
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
