Satec PM174 User Manual

32
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
… R
+14,15 0x4207
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
7872-7887 Billing TOU Energy Register #7
+0,1 0x4300
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4301
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4307
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
7936-7951 Billing TOU Energy Register #8
+0,1 0x4400
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4401
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4407
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
8000-8007 Billing Summary Accumulated Demands
+0 0x4500
Summary register #1 demand
0-Pmax U3 UINT16 R
+1 0x4501
Summary register #2 demand
0-Pmax U3 UINT16 R
… R
+7 0x4507
Summary register #8 demand
0-Pmax U3 UINT16 R
8032-8039 Billing Summary Block Demands
+0 0x4580
Summary register #1 demand
0-Pmax U3 UINT16 R
+1 0x4581
Summary register #2 demand
0-Pmax U3 UINT16 R
… R
+7 0x4587
Summary register #8 demand
0-Pmax U3 UINT16 R
8064-8071 Billing Summary Sliding Window Demands
+0 0x4600
Summary register #1 demand
0-Pmax U3 UINT16 R
+1 0x4601
Summary register #2 demand
0-Pmax U3 UINT16 R
… R
+7 0x4607
Summary register #8 demand
0-Pmax U3 UINT16 R
8160-8167 Billing Summary Maximum Demands
+0 0x4780
Summary register #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4781
Summary register #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4787
Summary register #8 maximum demand
0-Pmax U3 UINT16 R
8192-8199 Billing TOU Maximum Demand Register #1
+0 0x4800
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4801
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4807
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
8256-8263 Billing TOU Maximum Demand Register #2
+0 0x4900
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4901
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
