Satec PM174 User Manual

33
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
+7 0x4907
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
8320-8327 Billing TOU Maximum Demand Register #3
+0 0x4A00
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4A01
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4A07
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
8224-8231 Billing TOU Maximum Demand Register #4
+0 0x4880
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4881
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4887
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
8288-8295 Billing TOU Maximum Demand Register #5
+0 0x4980
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4981
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4987
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
8352-8359 Billing TOU Maximum Demand Register #6
+0 0x4A80
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4A81
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4A87
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
8896-8903 Billing TOU Maximum Demand Register #7
+0 0x5300
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x5301
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x5307
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
8928-8935 Billing TOU Maximum Demand Register #8
+0 0x5380
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x5381
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x5387
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
9984-10033 V1/V12 Harmonic Angles
2, 4
+0 0x6400
H01 Harmonic angle
-180.0-180.0 0.1º INT16 R
+1 0x6401
H02 Harmonic angle
-180.0-180.0 0.1º INT16 R
...
+49 0x6431
H50 Harmonic angle
-180.0-180.0 0.1º INT16 R
10048-10097 V2/V23 Harmonic Angles
2, 4
+0 0x6500
H01 Harmonic angle
-180.0-180.0 0.1º INT16 R
+1 0x6501
H02 Harmonic angle
-180.0-180.0 0.1º INT16 R
...
+49 0x6531
H50 Harmonic angle
-180.0-180.0 0.1º INT16 R
