Satec PM174 User Manual

41
Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
14848-14865 Phase Energies
+0,1 0x1800
kWh import L1
0-999,999,999 1 kWh UINT32 R
+2,3 0x1801
kWh import L2
0-999,999,999 1 kWh UINT32 R
+4,5 0x1802
kWh import L3
0-999,999,999 1 kWh UINT32 R
+6,7 0x1803 kvarh import L1 0-999,999,999 1 kvarh UINT32 R
+8,9 0x1804 kvarh import L2 0-999,999,999 1 kvarh UINT32 R
+10,11 0x1805 kvarh import L3 0-999,999,999 1 kvarh UINT32 R
+12,13 0x1806 kVAh total L1 0-999,999,999 1 kVAh UINT32 R
+14,15 0x1807 kVAh total L2 0-999,999,999 1 kVAh UINT32 R
+16,17 0x1808 kVAh total L3 0-999,999,999 1 kVAh UINT32 R
14912-14931 Symmetrical Components
+0, 1 0x1880 Positive-sequence voltage 0-Vmax U1 UINT32 R
+2, 3 0x1881 Negative-sequence voltage 0-Vmax U1 UINT32 R
+4, 5 0x1882 Zero-sequence voltage 0-Vmax U1 UINT32 R
+6, 7 0x1883 Negative-sequence voltage unbalance 0-3000
×0.1%
UINT32 R
+8, 9 0x1884 Zero-sequence voltage unbalance 0-3000
×0.1%
UINT32 R
+10, 11 0x1885 Positive-sequence current 0-Imax U2 UINT32 R
+12, 13 0x1886 Negative-sequence current 0-Imax U2 UINT32 R
+14, 15 0x1887 Zero-sequence current 0-Imax U2 UINT32 R
+16, 17 0x1888 Negative-sequence current unbalance 0-3000
×0.1%
UINT32 R
+18, 19 0x1889 Zero-sequence current unbalance 0-3000
×0.1%
UINT32 R
14976-15075 V1/V12 Harmonic Distortion
2
+0,1 0x1900
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1901
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+98,99 0x1931
H50 Harmonic distortion
0-10000 0.01% UINT32 R
15104-15203 V2/V23 Harmonic Distortion
2
+0,1 0x1A00
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1A01
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+98,99 0x1A31
H50 Harmonic distortion
0-10000 0.01% UINT32 R
15232-15331 V3/V31 Harmonic Distortion
2
+0,1 0x1B00
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1B01
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+98,99 0x1B31
H50 Harmonic distortion
0-10000 0.01% UINT32 R
15360-15459 I1 Harmonic Distortion
+0,1 0x1C00
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1C01
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+98,99 0x1C31
H50 Harmonic distortion
0-10000 0.01% UINT32 R
