Satec PM174 User Manual

40
Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
+6,7 0x1603 I1 Ampere demand 0-Imax U2 UINT32 R
+8,9 0x1604 I2 Ampere demand 0-Imax U2 UINT32 R
+10,11 0x1605 I3 Ampere demand 0-Imax U2 UINT32 R
+12,13 0x1606 kW import block demand 0-Pmax U3 UINT32 R
+14,15 0x1607 kvar import block demand 0-Pmax U3 UINT32 R
+16,17 0x1608 kVA block demand 0-Pmax U3 UINT32 R
+18,19 0x1609 kW import sliding window demand 0-Pmax U3 UINT32 R
+20,21 0x160A kvar import sliding window demand 0-Pmax U3 UINT32 R
+22,23 0x160B kVA sliding window demand 0-Pmax U3 UINT32 R
+24,25 0x160C Not used UINT32 R
+26,27 0x160D Not used UINT32 R
+28,29 0x160E Not used UINT32 R
+30,31 0x160F kW import accumulated demand 0-Pmax U3 UINT32 R
+32,33 0x1610 kvar import accumulated demand 0-Pmax U3 UINT32 R
+34,35 0x1611 kVA accumulated demand 0-Pmax U3 UINT32 R
+36,37 0x1612 kW import predicted sliding window demand 0-Pmax U3 UINT32 R
+38,39 0x1613 kvar import predicted sliding window demand 0-Pmax U3 UINT32 R
+40,41 0x1614 kVA predicted sliding window demand 0-Pmax U3 UINT32 R
+42,43 0x1615 PF (import) at Max. kVA sliding window demand 0-1000
×0.001
UINT32 R
+44,45 0x1616 kW export block demand 0-Pmax U3 UINT32 R
+46,47 0x1617 kvar export block demand 0-Pmax U3 UINT32 R
+48,49 0x1618 kW export sliding window demand 0-Pmax U3 UINT32 R
+50,51 0x1619 kvar export sliding window demand 0-Pmax U3 UINT32 R
+52,53 0x161A kW export accumulated demand 0-Pmax U3 UINT32 R
+54,55 0x161B kvar export accumulated demand 0-Pmax U3 UINT32 R
+56,57 0x161C kW export predicted sliding window demand 0-Pmax U3 UINT32 R
+58,59 0x161D kvar export predicted sliding window demand 0-Pmax U3 UINT32 R
14720-14737 Total Energies
+0,1 0x1700
kWh import
0-999,999,999 1 kWh UINT32 R
+2,3 0x1701 kWh export 0-999,999,999 1 kWh UINT32 R
+4,5 0x1702 Not used INT32 R
+6,7 0x1703 Not used UINT32 R
+8,9 0x1704 kvarh import 0-999,999,999 1 kvarh UINT32 R
+10,11 0x1705 kvarh export 0-999,999,999 1 kvarh UINT32 R
+12,13 0x1706 Not used INT32 R
+14,15 0x1707 Not used UINT32 R
+16,17 0x1708 kVAh total 0-999,999,999 1 kVAh UINT32 R
14784-14799 Billing Summary Energy Registers
+0,1 0x1780
Summary energy register #1
0-999,999,999 1 kWh UINT32 R
+2,3 0x1781
Summary energy register #2
0-999,999,999 1 kWh UINT32 R
…
+14,15 0x1787
Summary energy register #8
0-999,999,999 1 kWh UINT32 R
