Satec PM174 User Manual

39
Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
+54,55 0x111B I1 Current TDD 0-1000
×0.1%
UINT32 R
6
+56,57 0x111C I2 Current TDD 0-1000
×0.1%
UINT32 R
6
+58,59 0x111D I3 Current TDD 0-1000
×0.1%
UINT32 R
6
+60,61 0x111E V12 Voltage 0-Vmax U1 UINT32 R
+62,63 0x111F V23 Voltage 0-Vmax U1 UINT32 R
+64,65 0x1120 V31 Voltage 0-Vmax U1 UINT32 R
14336-14343 1-Second Total Values
+0,1 0x1400 Total kW -Pmax-Pmax U3 INT32 R
+2,3 0x1401 Total kvar -Pmax-Pmax U3 INT32 R
+4,5 0x1402 Total kVA 0-Pmax U3 UINT32 R
+6,7 0x1403 Total PF -1000-1000
×0.001
INT32 R
+8,9 0x1404 Total PF lag 0-1.000
×0.001
UINT16 R
+10,11 0x1405 Total PF lead 0-1.000
×0.001
UINT16 R
+12,13 0x1406 Total kW import 0-Pmax U3 UINT32 R
+14,15 0x1407 Total kW export 0-Pmax U3 UINT32 R
+16,17 0x1408 Total kvar import 0-Pmax U3 UINT32 R
+18,19 0x1409 Total kvar export 0-Pmax U3 UINT32 R
+20,21 0x140A 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R
1
+22,23 0x140B 3-phase average L-L voltage 0-Vmax U1 UINT32 R
+24,25 0x140C 3-phase average current 0-Imax U2 UINT32 R
14464-14473 1-Second Auxiliary Values
+0,1 0x1500 Not used UINT32 R
+2,3 0x1501 In (neutral) Current 0-Imax U2 UINT32 R
+4,5 0x1502 Frequency 0-Fmax
×0.01Hz
UINT32 R
+6,7 0x1503 Voltage unbalance 0-3000
×0.1%
UINT32 R
+8,9 0x1504 Current unbalance 0-3000
×0.1%
UINT32 R
14528-14551 Present Harmonic Demands
+0,1 0x1580 V1/V12 THD demand 0-9999
×0.1%
UINT32 R
2
+2,3 0x1581 V2/V23 THD demand 0-9999
×0.1%
UINT32 R
2
+4,5 0x1582 V3/V31 THD demand 0-9999
×0.1%
UINT32 R
2
+6,7 0x1583 Not used UINT32 R
+8,9 0x1584 I1 THD demand 0-9999
×0.1%
UINT32 R
+10,11 0x1585 I2 THD demand 0-9999
×0.1%
UINT32 R
+12,13 0x1586 I3 THD demand 0-9999
×0.1%
UINT32 R
+14,15 0x1587 Not used UINT32 R
+16,17 0x1588 I1 TDD demand 0-1000
×0.1%
UINT32 R
+18,19 0x1589 I2 TDD demand 0-1000
×0.1%
UINT32 R
+20,21 0x158A I3 TDD demand 0-1000
×0.1%
UINT32 R
+22,23 0x158B Not used UINT32 R
14592-14651 Present Volt, Ampere and Power Demands
+0,1 0x1600 V1/V12 Volt demand 0-Vmax U1 UINT32 R
2
+2,3 0x1601 V2/V23 Volt demand 0-Vmax U1 UINT32 R
2
+4,5 0x1602 V3/V31 Volt demand 0-Vmax U1 UINT32 R
2
