Satec PM174 User Manual

88
Format Code Value Description Notes
0x8603 Status input #4 OFF
Pulse Inputs
0x0700 Pulse input #1
0x0701 Pulse input #2
0x0702 Pulse input #3
0x0703 Pulse input #4
Relays
0x0800 Relay #1 ON
0x0801 Relay #2 ON
0x0802 Relay #3 ON
0x0803 Relay #4 ON
0x8800 Relay #1 OFF
0x8801 Relay #2 OFF
0x8802 Relay #3 OFF
0x8803 Relay #4 OFF
Static Events
0x8901 Positive phase rotation reversal
3
0x8902 Negative phase rotation reversal
3
0x0903 IEEE 1159 PQ event
Pulse Counters
0x0A00 High pulse counter #1
0x0A01 High pulse counter #2
0x0A02 High pulse counter #3
0x0A03 High pulse counter #4
Time and Date Parameters
0x0B02 Day of week
0x0B03 Year
0x0B04 Month
0x0B05 Day of month
0x0B06 Hour
0x0B07 Minutes
0x0B08 Seconds
0x0B09 Minute interval (1,2,3,4,5,10,15,20,30,60 min)
1-Cycle Phase Values
0x0C03 High I1 current
0x0C04 High I2 current
0x0C05 High I3 current
0x8C03 Low I1 current
0x8C04 Low I2 current
0x8C05 Low I3 current
1-Cycle Values on any Phase
0x0E00 High voltage
1
0x8D00 Low voltage
1
0x0E01 High current
0x8D01 Low current
0x0E07 High voltage THD
1
0x0E08 High current THD
1
0x0E09 High K-Factor
0x0E0A High current TDD
1-Cycle Auxiliary Values
0x1001 High neutral current
0x1002 High frequency
0x9002 Low frequency
0x1003 High voltage unbalance
1
0x1004 High current unbalance
1-Sec Phase Values
0x1103 High I1 current
0x1104 High I2 current
0x1105 High I3 current
0x9103 Low I1 current
0x9104 Low I2 current
0x9105 Low I3 current
1-Sec Values on any Phase
0x1300 High voltage
1
0x9200 Low voltage
1
0x1301 High current
0x9201 Low current
