Satec PM174 User Manual

49
Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
25984-26021 10-Minute Total Harmonics
+0, 1 0x6F00 V1 THD 0-9999
×0.1%
UINT32 R
2
+2, 3 0x6F01 V2 THD 0-9999
×0.1%
UINT32 R
2
+4, 5 0x6F02 V3 THD 0-9999
×0.1%
UINT32 R
2
+6, 7 0x6F03 Reserved 0 UINT32 R
+8, 9 0x6F04 I1 THD 0-9999
×0.1%
UINT32 R
+10, 11 0x6F05 I2 THD 0-9999
×0.1%
UINT32 R
+12, 13 0x6F06 I3 THD 0-9999
×0.1%
UINT32 R
+14, 15 0x6F07 Reserved 0 UINT32 R
+16, 17 0x6F08 V1 Inter-harmonics THD 0-9999
×0.1%
UINT32 R
2
+18, 19 0x6F09 V2 Inter-harmonics THD 0-9999
×0.1%
UINT32 R
2
+20, 21 0x6F0A V3 Inter-harmonics THD 0-9999
×0.1%
UINT32 R
2
+22, 23 0x6F0B Reserved 0 UINT32 R
+24, 25 0x6F0C I1 Inter-harmonics THD 0-9999
×0.1%
UINT32 R
+26, 27 0x6F0D I2 Inter-harmonics THD 0-9999
×0.1%
UINT32 R
+28, 29 0x6F0E I3 Inter-harmonics THD 0-9999
×0.1%
UINT32 R
+30, 31 0x6F0F Reserved 0 UINT32 R
+32, 33 0x6F10 I1 TDD 0-1000
×0.1%
UINT32 R
+34, 35 0x6F11 I2 TDD 0-1000
×0.1%
UINT32 R
+36, 37 0x6F12 I3 TDD 0-1000
×0.1%
UINT32 R
Generic TOU Season Energy Registers Point references
0x7000
Tariff #1 register
0-999,999,999 1 kWh UINT32
0x7001
Tariff #2 register
0-999,999,999 1 kWh UINT32
…
0x7007
Tariff #8 register
0-999,999,999 1 kWh UINT32
Generic TOU Season Maximum Demand
Registers
Point references
0x7100
Tariff #1 register
0-Pmax U3 UINT32
0x7101
Tariff #2 register
0-Pmax U3 UINT32
…
0x7107
Tariff #8 register
0-Pmax U3 UINT32
Generic Data Point references
0x7400 V1 voltage 0-Vmax U1 UINT32
0x7401 V2 voltage 0-Vmax U1 UINT32
0x7402 V3 voltage 0-Vmax U1 UINT32
0x7404 V12 voltage 0-Vmax U1 UINT32
0x7405 V23 voltage 0-Vmax U1 UINT32
0x7406 V31 voltage 0-Vmax U1 UINT32
0x7407 I1 current 0-Imax U2 UINT32
0x7408 I2 current 0-Imax U2 UINT32
0x7409 I3 current 0-Imax U2 UINT32
0x7414 Voltage unbalance 0-3000
×0.1%
UINT32
