100 Programming SATEL
Events assignment
If the events are to be sent to both stations (STATION 1 AND 2 is selected), you can define
which event types will be reported to the given station.
It is not possible to assign events for the CONTACT ID (FULL) and SIA (FULL) formats.
12.1.3 SIA-IP
If events are to be sent in the SIA-IP format, you must program additional parameters for
each monitoring station.
Send MAC address [MAC] – if this option is enabled, the MAC address of ETHM-1 /
ETHM-1 Plus module will be sent with event code.
Send timestamp [Timestamp] – if this option is enabled, the date and time will be sent with
event code (the monitoring station can change the date and time in the control panel).
Encrypt data [Coded] – if this option is enabled, the data to be sent will be encrypted, and
the date and time will be sent with event code (the monitoring station can change the date
and time in the control panel).
SIA-IP key – the key to encrypt data to be sent using the SIA-IP format.
hex – if the option is enabled, you can enter up to 32 hexadecimal characters as the SIA-IP
KEY
. If the option is disabled, you can enter up to 16 alphanumeric characters as the
SIA-IP KEY.
SIA-IP acct – a string of up to 16 hexadecimal characters, which is used to identify the
control panel for the purpose of reporting in SIA-IP format.
Supervision interval [SIA-IP test] – an additional transmission can be sent at specified
intervals to check communication with the monitoring station. You can program a number
of days, hours, minutes and seconds between the transmissions.
Event-independent pooling [Ev.independent] – if this option is enabled, an additional
transmission to check communication is sent after the programmed time has elapsed since
the last such transmission. If this option is disabled, an additional transmission to check
communication is sent after the programmed time has elapsed since any last transmission.
12.1.4 Identifiers assignment
Define the identifier with which events relating to individual partitions, zones, keypads and
expansion modules will be sent. If no identifier is assigned to the given element of the
system, it will be impossible to define codes for events relating to it.
12.1.5 Event codes
For the pulse and Ademco Express formats, it is necessary to program codes which will be
reported to the monitoring station if the defined events occur. The reported events are those
for which a code different from “00” has been programmed. 2 hexadecimal characters (digits
or letters from A to F) are to be programmed.
In case of the CONTACT ID (SELECTED) and SIA (SELECTED) formats, indicate the events
which are to be reported, entering for them any code different from “00” (a code
consistent with the format specification will be sent, not the entered one). The events
for which the “00” code has been programmed will not be reported.
12.1.6 Test transmissions
The test transmission may be sent:
• at a specified time. The test transmission code will be sent regularly at a defined time. The
number of days between transmissions and the time of sending transmission are
programmed.
