SATEL INTEGRA 61
by beeps in keypad (violation – 5 short beeps; tamper – 1 long beep; masking – 3 long
beeps). Additionally, the function allows selection of a system output which will be used for
signaling during the test (zone violation will activate the output for 0.4 second, tamper – for
1,6 seconds, masking – for 3 seconds).
Violation/tamper/masking of the zone during the test will not trigger the response
programmed for the control panel zone.
Select a zone for testing from the list and press the or
key. The output allocated
for signaling will stop doing its present duty (if it was active, it will be disabled) until the
zone test is completed (the key pressed).
The output used for signaling is only remembered until exiting the TEST function. When
the TEST function is re-started, the output must be selected again.
If wireless sirens are used in the system and any output is selected for signaling, after
selecting a zone for testing from the list and pressing the or
key, in the wireless
sirens the signaling will be unblock (which is normally blocked for the service mode
duration).
If the output selected for signaling controls the wireless siren, it should be borne in
mind that the command to block/unblock signaling is sent out during polling. This
results in a delay whose duration depends on the programmed response period. Also
in case of the ASP-205 siren signaling is only triggered during the polling period.
5. Outputs
The system supports the following outputs:
• hardwired – on the control panel electronics board and in expanders. The number of
available hardwired outputs is determined by the control panel during identification
procedure.
• wireless – in the INTEGRA 128-WRL control panel or after connecting the ABAX 2 /
ABAX wireless system controller. The number of available wireless outputs depends on
the number of wireless devices registered in the system and is determined during the
procedure of adding wireless devices.
• virtual – the outputs which do not exist physically, but can be used e.g. for execution of
logical functions.
Programming of the outputs is possible:
• using the keypad, in the service mode, by means of the functions available in the OUTPUTS
submenu,
• using the DLOADX program, in the “Outputs” window.
5.1 Output parameters
Output name – individual name of the output (up to 16 characters).
Output function (see: “Output functions”).
Cut off time – time during which the output is active. The cut-off time can be programmed
with an accuracy of up to 0.1 second. The parameter is irrelevant for the status indicating
outputs.
To set the cut-off time with an accuracy of up to 0.1 sec using the DLOADX program,
right-click on the “Cut off time” column. A pop-up menu will appear, in which you must
click on “Edit”.
