SATEL INTEGRA 35
3.3 Local programming
3.3.1 Starting local programming
1. Connect the control panel RS-232 port to the computer port (for the connection method
please refer to the INSTALLER MANUAL).
2. Start the DLOADX program and click on the button. A window will open in which
you should select the computer port to which the control panel is connected. Press “OK”.
3. On the LCD keypad connected to the control panel, enter the service code (by default
12345) and press the
key.
4. Using the or key, find the DOWNLOADING submenu and press the or key.
5. When the arrow indicates the START DWNL-RS function, press the or key.
To start the local programming function you can use the [service code] 01 key
shortcut.
6. Establishing communication will be signaled on the monitor screen by a corresponding
message.
3.3.2 Starting local programming “from pins”
If the control panel does not support LCD keypads, does not accept the service code, etc.,
you can use the emergency procedure of, so-called, starting “from pins”. The control panel
RS-232 port must be connected to the computer. In the DLOADX program, indicate the
computer port to which the control panel is connected. Then, follow the procedure described
in section “Starting the service mode “from pins”” (p. 6).
Running the local programming “from pins” is not possible, if the DISABLE
DOWNLOADING option is enabled.
3.3.3 Finishing local programming
To end the local programming you can use the END DWNL-RS function ([service code]
DOWNLOADING END DWNL-RS).
The local programming function will be finished automatically after 255 minutes have elapsed
since the last use of the DLOADX program, and the service access was blocked or expired
during that time.
The local programming function must be disabled, if the control panel is to
communicate through the RS-232 port with an external analog modem, GSM module,
INT-GSM / INT-GSM LTE module or ETHM-1 / ETHM-1 Plus module (e.g. during
remote programming, event reporting, etc.).
3.4 Remote programming
3.4.1 Starting remote programming via modem
The control panel has a built-in 300 bps modem. The GSM communicator of
INTEGRA 128-WRL control panel supports sending data with the use of CSD technology, i.e.
at a rate of 9600 bps. In case of the other control panels, higher transmission rates can be
obtained after an external modem is connected. For information on how to connect the
external modem to the control panel please refer to the INSTALLER MANUAL. Initializing the
modem connection is possible, if there is a properly matched modem on the computer side
(see Table 4).
