26 Programming SATEL
Described below are general rules for entering data, however they may be different as
regards some functions.
2.6.1 Selection from the single-choice list
The upper line of display shows the function name, and the lower one – the currently
selected item. To scroll through the item list, use the keys (down) and the keys (up).
The and keys are not used.
2.6.2 Selection from the multiple-choice list
The functions that allow you to make multiple choice can be identified by an additional
symbol situated at the right-hand side of the display:
– displayed item is selected / option is enabled,
– displayed item is not selected / option is disabled.
Pressing any digit key (for some functions, this does not work with the key 0) will change the
currently displayed symbol to the other one. To scroll through the list of items, use the key
(down) or the key (up). For some functions, pressing the key 0 will allow you to enter the
number of item to be edited (e.g. the number of partition or zone). This will speed up search.
For some functions, pressing the or key will switch the keypad into the graphic
programming mode. The and symbols are used to present on the display the current
status of up to 32 items available in the given function (these can be e.g. zones, outputs,
timers, etc.). The key moves the cursor to the right, and the key to the left. If the list of
items is longer than 32, pressing the key when the cursor is placed over the last item will
display the next list, and pressing the key when the cursor is placed over the first item will
display the previous list. Pressing the key 0, 1 or 2 three times in the graphic mode within 3
seconds will have the following effect:
000 - the symbol will be displayed at all available items,
111 - the symbol will be displayed at all available items,
222 - reversal of the selection made: the symbol will be displayed at all items where
the symbol was displayed, and the symbol where the symbol was displayed.
On pressing the or key, the keypad will return to the text mode.
2.6.3 Entering decimal and hexadecimal values
Digits are entered by pressing the suitable keys. Characters from A to F are available under
the keys with numbers 2 and 3. Keep pressing the keys until the required character appears.
2.6.4 Programming telephone numbers
Keep pressing particular keys until the required character appears. Characters available in
the keypad are presented in Table 1. Up to 16 characters can be programmed. Some of the
special characters (a, b, c, d, # and ) are coded so that the character takes up two items,
hence the maximum number of characters available for entering, if they are used, will be
lower.
Shown on the left side in the upper line of the display is information about the letter case:
[ABC] or [abc] (it will be displayed after pressing the key, which changes the letter case,
and will be visible for a few seconds after the last keystroke).
The key moves the cursor to the right, and the key – to the left. The key deletes the
character on the left side of the cursor.
