Satel Integra 64 - Assigning Zones to a Partition; Programming the EOL Resistor Values

SATEL INTEGRA 51
• wireless – in the INTEGRA 128-WRL control panel or after connecting the ABAX 2 /
ABAX wireless system controller. The number of available wireless zones depends on the
number of wireless devices registered in the system and is determined during the
procedure of adding the devices.
• virtual – zones which physically do not exist, but have been programmed as FOLLOW
OUTPUT
or are controlled by means of a keyfob.
4.3.1 Assigning zones to a partition
The zones can be assigned to a partition:
• using the keypad, in the service mode, by means of the ZONES function (STRUCTURE
SYSTEM PARTITIONS SETTINGS [Part. Name] ZONES) – see: “Selection from the
multiple-choice list” p. 26,
• using the DLOADX program:
1. in the “Structure” window, “System” tab, after clicking on the partition name. Click on
the “Add” button to display the list of zones which can be assigned to the selected
partition. Click on the zone which is to be assigned to the partition.
2. in the “Zones” window, “Zones” tab, “Part.” column, enter the number of partition to
which the given zone is to be assigned.
4.3.2 Programming the EOL resistor values
For the zones on INTEGRA 128-WRL control panel mainboard, some keypads and
expanders, the value of end-of-line resistors is programmable within the range from 500 Ω to
15 kΩ (the sum of preset values may not exceed 15 kΩ).
The value of EOL resistors for the zones on the INTEGRA 128-WRL control panel mainboard
can be programmed:
• using the keypad, in the service mode, by means of EOL R1 RESISTOR and EOL R2
RESISTOR
functions (STRUCTURE HARDWARE EOL R1 RESISTOR / EOL R2 RESISTOR),
• using the DLOADX program, in the “Structure” window, “Hardware” tab, after clicking on
the control panel mainboard.
The value of EOL resistors programmed for the INTEGRA 128-WRL mainboard zones
applies also to the zones in the keypads:
− INT-KLCD and INT-KLCDR with electronics version 3.2 and firmware version 2.11
(or newer),
− INT-KLFR.
The value of EOL resistors for the zones in expanders can be programmed:
• using the keypad, in the service mode, by means of EOL R1 RESISTOR and EOL R2
RESISTOR
functions (STRUCTURE HARDWARE EXPANDERS SETTINGS [expander
name]  EOL R1 RESISTOR /  EOL R2 RESISTOR),
• using the DLOADX program, in the “Structure” window, “Hardware” tab, after clicking on
the given expander.
For the zones in INT-KSG / INT-TSG / INT-TSG2 / INT-TSH / INT-TSH2 keypad, the value of
EOL resistors is programmed in the DLOADX program, “Structure” window, “Hardware” tab.
After clicking on the given keypad, select the corresponding tab. The value of these resistors
cannot be programmed from the keypad.
