SATEL INTEGRA 71
3. Program the output 62, which does not exist physically, as 26. TIMER type. Program the
timer, which is to control the output, as a daily one, turned on at 16.00 and turned off at
8.00.
4. Program the output 2, to which the siren is connected, as 46. OUTPUTS LOGICAL AND, and
indicate the outputs 1 and 62 as the controlling outputs. As a result, the output 2 will
signal alarms and confirmation of partition arming/disarming, but only from 16:00 to 8:00.
Beyond these hours, the output will be inactive.
5.10 Output testing
Using the function available in the service mode menu in the keypad (OUTPUTS TEST),
you can test the outputs. After starting the function, the list of system outputs will be
displayed. Select the output to be tested and press the
or key. The keypad will display
a submenu which enables the output testing. By using the or key, you can
activate/deactivate the output. You can also deactivate the output by means of the numerical
keys. Press to quit the submenu and return to the list of system outputs.
The output under test will stop performing its previous function (if it was active, it will
be deactivated).
If there are wireless sirens in the system, starting the function of output testing will
unblock the signaling in them (the signaling is normally blocked for the service mode
duration). It should be remembered that the command to block/unblock the signaling is
sent out during polling. This will cause a delay whose duration depends on the
programmed response period.
When testing the control output for ASP-205 wireless siren, it should be remembered
that the signaling is only triggered during the polling.
6. System options
Most of the options and parameters described in this section can be programmed:
• using the keypad, in the service mode, by means of the functions available in the OPTIONS
submenu,
• using the DLOADX program, in the “Options” window.
Shown in square brackets are the names used in keypads.
6.1 Telephone options
Reporting - TELEPHONE [Mon.TELEPHONE] – with this option enabled, the control panel
can send event codes by means of the telephone line (in the case of INTEGRA 128-WRL
control panel – the GSM voice channel).
Reporting - GPRS [Mon.GPRS] – if the option is enabled:
– the INTEGRA 128-WRL control panel can send event codes via the cellular data
network (GPRS),
– any control panel can send event codes via the cellular data network (LTE/GPRS) by
using the SATEL GSM module.
The REPORTING – GPRS option does not apply to reporting via the cellular data
network by using the INT-GSM / INT-GSM LTE module.
Reporting - ETHM [Mon.ETHM-1] – the option is available if the ETHM-1 Plus / ETHM-1
module is connected to the control panel, but the INT-GSM / INT-GSM LTE module is not
included in the alarm system. If this option is enabled, the control panel can send event
codes over Ethernet by using the ETHM-1 Plus / ETHM-1 module.
