54 Programming SATEL
Zone sensitivity – depending on wiring type:
NO, NC, EOL, 2EOL/NC, 2EOL/NO – the time during which the zone must be violated, so
that it can be noted by the control panel.
Roller – 2 parameters are to be programmed (in the DLOADX program, you should enter
two numbers in the ZONE SENSITIVITY field):
Pulses duration – the time period during which a specified number of pulses must
occur (PULSES COUNT) for the zone to be violated. You can enter 0 (the pulse counter
will only be reset on arming / disarming), 1 (30 seconds), 2 (120 seconds) or 3 (240
seconds).
Pulses count – the number of pulses after which the zone will be violated. You can
program values from 1 to 8.
Vibration – 2 parameters are to be programmed (in the DLOADX program, you should
enter two numbers in the ZONE SENSITIVITY field):
Sensitivity – occurrence of a shock whose duration is equal to or longer than the
defined time will cause violation of the zone. You can program values from the 3 ms
to 96 ms range (every 3 ms).
Pulses count – the number of shocks after which the zone will be violated. You can
program values from 0 to 7. If the value 0 is programmed, the pulses (shocks) will not
be counted – only SENSITIVITY will be taken into account.
Output – refers to the FOLLOW OUTPUT wiring type. Indicate the number of output whose
activation will violate the zone. The output can be a virtual one.
Max. violation time / Max. door opening time – exceeding the maximum time of
violation/door opening is recognized by the control panel as a detector failure/door failure.
If the value 0 is programmed, control of this time is disabled.
Max. no violation time – exceeding the maximum time of no violation is recognized by the
control panel as a detector failure. The time will only be counted when the zone is
disarmed. If the value 0 is programmed, control of this time is disabled. The time can be
programmed in hours or minutes.
It is recommended that you program the MAX. NO VIOLATION TIME parameter, since it will
provide an additional supervision of the detector connected to the zone.
4.3.5 Zone types
0. ENTRY/EXIT – a delayed zone combining two functions:
entry – violation of the zone starts entry delay counting in the partition and turns on delay
for the 3. INTERIOR DELAYED type zones,
exit – violation of the zone during exit delay countdown is equivalent to the partition exit.
1. ENTRY – violation of the zone starts entry delay counting in the partition and turns on delay
for the 3. INTERIOR DELAYED type zones.
2. DELAYED – a delayed-action zone with optional signaling of delay countdown in keypads.
3. INTERIOR DELAYED – the zone operates as a delayed one when:
– violation of another zone has triggered the entry delay countdown in the partition,
– the delay will be activated using the INT-ENT entry keypad (see the INT-SCR
multifunction keypad manual),
– arm mode type 2 or 3 is active and the DELAY IN 2&3 TYPE ARMING option is enabled for
the zone.
In other situations, the zone will act as an instant one.
4. PERIMETER – instant zone, which is already armed during exit delay countdown.
5. INSTANT – instant zone.
