116. INTERNAL SIREN – signals the same alarms and violations as the 1. BURGLARY or 9. DAY
ALARM output type (logic product of the 1. BURGLARY and 9. DAY ALARM outputs).
117. TAMPERING STATUS – informs about tamper of selected zones, keypads and expanders.
118. KEYFOB BATTERY LOW – informs about low battery in keyfobs belonging to selected
users. Refers to the 433 MHz keyfobs (supported by the INT-RX or INT-RX-S modules) or
the APT-200 (supported by the ABAX 2 / ABAX system) / APT-100 keyfobs (supported by
the ABAX system).
119. WIRELESS SYSTEM JAMMING – indicates the jamming of device supporting the ABAX 2
(ACU-220 or ACU-280 controller) / ABAX wireless system (INTEGRA 128-WRL control
panel, ACU-120, ACU-270, ACU-100 or ACU-250 controllers).
120. THERMOSTAT – the output activates when temperature drops below a preset value. The
control panel can receive the temperature data from wireless temperature detectors or
ABAX 2 wireless devices provided with a temperature sensor. For more information, refer
to section “120. Thermostat output settings” p. 68.
5.3 Options
Pol.+ – defines the output operating mode (see Table 5).
high-current output
option enabled
(normal polarity)
option disabled
(reversed polarity)
active status
+12V voltage supply
+12V voltage cut-off
inactive status
+12V voltage cut-off
+12V voltage supply
low-current output
option enabled
(normal polarity)
option disabled
(reversed polarity)
active status
shorted to ground
isolated from ground
inactive status
isolated from ground
shorted to ground
Table 5. Functioning of outputs, depending on the POL.+ option.
Pulsating – the option refers to timed outputs. If it is enabled, the output operates in
a pulsating mode. If it is disabled, the output operates continuously.
Latch – the option refers to alarm outputs. If it is enabled, the output will be active until the
alarm is cleared by the user.
Active during violation – the option applies to the 24. MONO SWITCH output. If enabled, the
output is always active when a control zone is violated, and the countdown of output cut-
off time will only be running after the violation ends.
Timer activates/deactivates – the option applies to the 24. MONO SWITCH and 25. BI SWITCH
outputs. If enabled, the output can be controlled by selected timers. Turning the timer ON
activates the output (in case of the 24. MONO SWITCH type output – for a programmed
time), and turning the timer OFF deactivates the output.
ON/OFF – the option refers to the 24. MONO SWITCH type outputs. If it is enabled, violation of
the control zone when the output is on will turn the output off. If the option is disabled,
each violation of the control zone will turn the output on for a preset time.
AC loss fast – the option refers to the 28. AC LOSS (MAINBOARD)-IMMEDIATE type outputs. If
this option is enabled, the output will be activated immediately after the AC power is lost. If
this option is disabled, the output will be activated 10 seconds after the AC power is lost.
Not controlled by arming – the option refers to the 105. SHUTTER UP and 106. SHUTTER
DOWN
type outputs. If enabled, the partition arming / disarming has no effect on the output
status.
