Satel Integra 64 - Configuring the Wireless Devices - DLOADX Program

SATEL INTEGRA 89
ASD-150 (ASD-250) – wireless smoke detector. You can configure:
 option to indicate alarm from other ASD-250 / ASD-150 detectors,
 option to send alarm to other ASD-250 / ASD-150 detectors.
ATD-100 (ATD-200) – wireless temperature detector. You can configure the temperature
threshold parameters for both positions occupied by the detector (which enables two
different temperature thresholds to be programmed):
 threshold type: high (when the temperature rises above the defined temperature,
alarm will be triggered) or low (when the temperature drops below the defined
temperature, alarm will be triggered),
 temperature,
 tolerance.
AVD-100 (AVD-200) – wireless shock detector and magnetic contact. You can:
 select the active reed switch of magnetic contact (not applicable to the AVD-200
detector, which does not have two reed switches) [first zone],
 configure the shock detector parameters [second zone]:
− sensitivity (registering a shock meeting the sensitivity criterion will trigger alarm),
− number of shocks, registering of which by the detector will trigger an alarm – the
shocks do not have to meet the sensitivity criterion (not applicable to the AVD-200
detector, which does not count the shocks).
Working parameters of the shock detector are independently analyzed. The detector
will report an alarm after a single strong shock caused by a heavy impact, as well as
after a series of weak shocks caused by a series of slight impacts.
ASP-105 – wirelessly triggered outdoor siren. You can configure:
 type of acoustic signaling,
 maximum duration of acoustic signaling.
ASP-205 (ASP-215) – wireless indoor siren. You can configure the signaling parameters
for both positions occupied by the siren (which enables two different types of signaling
to be programmed):
 maximum duration of signaling,
 type of acoustic signaling,
 optical signaling option.
ASW-100 (ASW-200) – 230 V AC smart plug. You can select operating mode.
ASW-210 – flush-mounted wireless two-channel 230 V AC controller. You can select the
operating mode of the controller inputs.
9.2.1 Configuring the wireless devices – DLOADX program
Described below is how the additional parameters and options should be programmed in the
“Configuration” column.
ADD-200
Dusk sensor – enter a number from the 1 to 16 range to determine sensitivity (1 – minimum;
16 – maximum).
Temperature sensor – enter in turn:
• letter H (high temperature threshold) or L (low temperature threshold),
• number from a range of -30 to +70 (with 0.5 accuracy) to define temperature,
• number from a range of 0.5 to 10 (with 0.5 accuracy) to define tolerance.
