SATEL INTEGRA 111
– switching over BI SWITCH type outputs.
Partitions – for some functions (arming/disarming, alarm clearing) you must indicate the
partitions where the function will be executed.
Zones – for some functions (bypassing/unbypassing zones) you must indicate the zones to
which the function applies.
Outputs – for some functions (activating/deactivating outputs) you must indicate the outputs
which will be controlled by the function.
Name – you can enter an individual name for the function. The name will be included in the
content of SMS message, with confirmation that the function has been executed.
Checking the system status
SMS [SMS check state] – the control command that can be sent in the SMS message to the
control panel phone number to check the state (status) of partitions. Having received the
SMS message, the control panel will send in response an SMS message containing
information on the partition status.
Report state of part. [Partitions list] – partitions whose status will be reported by the control
panel on receiving an SMS message with the control command.
Sending the network USSD codes
SMS [SMS USSD codes] – the control command which must precede the USSD code in the
SMS message sent to the control panel. The USSD codes make it possible e.g. to check
the account status of the SIM card installed in the control panel. Having received such an
SMS message, the control panel will execute the USSD code contained in it. The answer
obtained from the operator is sent in the form of SMS message to the telephone number
from which the control command was sent.
Using the advanced functions available due to the USSD service is not recommended
when menu is displayed in response to the code entered.
16. Control panel firmware update
Available on the www.satel.eu website is the current version of control panel firmware and
the FLASHX program enabling to write it to the control panel. In order to update the firmware:
1. Connect the control panel RS-232 port to the computer port (for the connection method
please refer to the INSTALLER MANUAL).
2. Start the FLASHX program.
3. Click on the button to select the file with control panel new firmware.
4. Click on the button to indicate the port to be used for communication with the control
panel and start the firmware update.
5. Using the function available in the service mode, start the STARTER program in the
control panel (RESTARTS STARTER).
During operation of the STARTER program the control panel does not perform
its normal functions (only the status of electronic fuses being monitored).
The STARTER program is waiting 2 minutes for the procedure of control panel
firmware update to begin. If it does not happen, the control panel will return to
the service mode.
