102 Programming SATEL
4. Program the following for the monitoring station to which event codes are to be sent:
– telephone number,
– reporting format in which the codes will be sent,
– the number of attempts to connect to the station after which, if there is no connection,
the control panel will suspend reporting (REPETITIONS),
– time for which reporting will be suspended after the programmed number of attempts to
establish connection with the station has been made (SUSPEND TIME),
– identifiers with which the events will be sent,
– events assignment (if STATION 1 AND 2 is selected),
– advanced options (if Ademco Express, Contact ID, SIA or TELIM format is selected).
5. If a reporting format other than CONTACT ID (FULL) or SIA (FULL) is selected:
– assign identifiers to the partitions, zones, keypads and expansion modules,
– program the codes for events which are to be reported.
6. Define the parameters of test transmissions.
12.2.2 Reporting via Ethernet network
The ETHM-1 / ETHM-1 Plus module must be connected to the control panel.
Events in TELIM format cannot be sent through Ethernet network.
1. Enable the REPORTING - ETHM-1 / REPORTING – ETHM/INT-GSM option.
2. Determine whether the event codes will be sent to both monitoring stations or to one of
them only (STATION 1 OR 2 / STATION 1 / STATION 2 / STATION 1 AND 2). If the INT-GSM /
INT-GSM LTE module is connected to the ETHM-1 Plus module, you can select the DUAL
PATH REPORTING
option.
3. Program the following for the monitoring station to which event codes are to be sent:
– reporting format in which the codes will be sent,
– server address,
– port number,
– IP format in which the codes will be sent (SATEL or SIA-IP),
– encryption key (STATION KEY) and control panel identifier for the purposes of reporting
via Ethernet (ETHM KEY) if the SATEL format is selected,
– additional parameters if the SIA-IP format is selected,
– identifiers with which the events will be sent,
– event assignment (if STATION 1 AND 2 is selected),
– advanced options if SIA reporting format is selected.
4. If a reporting format other than CONTACT ID (FULL) or SIA (FULL) is selected:
– assign identifiers to the partitions, zones, keypads and expansion modules,
– program the codes for events which are to be reported.
5. Define the parameters of test transmissions.
6. If the INT-GSM / INT-GSM LTE module is connected to the ETHM-1 Plus module, define
the priority of Ethernet reporting in the ETHM-1 Plus module settings.
12.2.3 Reporting via cellular data network
The TELIM format events cannot be sent via the cellular data network.
The Internet connection settings (APN, username, password, DNS server) must be
programmed in the INTEGRA 128-WRL control panel / INT-GSM / INT-GSM LTE
module / GSM module.
