SATEL INTEGRA 103
Reporting by using the INT-GSM / INT-GSM LTE module
1. Enable the REPORTING – ETHM/INT-GSM option.
2. Determine whether the event codes will be sent to both monitoring stations or to one of
them only (STATION 1 OR 2 / STATION 1 / STATION 2 / STATION 1 AND 2). If the INT-GSM /
INT-GSM LTE module is connected to the ETHM-1 Plus module, you can select the DUAL
PATH REPORTING
option.
3. Program the following for the monitoring station to which event codes are to be sent:
– reporting format in which the codes will be sent,
– server address,
– port number,
– IP format in which the codes will be sent (SATEL or SIA-IP),
– encryption key (STATION KEY) and control panel identifier for the purposes of reporting
via Ethernet (ETHM KEY) if the SATEL format is selected,
– additional parameters if the SIA-IP format is selected,
– identifiers with which the events will be sent,
– event assignment (if STATION 1 AND 2 is selected),
– advanced options if SIA reporting format is selected.
4. If a reporting format other than CONTACT ID (FULL) or SIA (FULL) is selected:
– assign identifiers to the partitions, zones, keypads and expansion modules,
– program the codes for events which are to be reported.
5. Define the parameters of test transmissions.
6. Define the priority of reporting via the cellular data network in the settings of INT-GSM /
INT-GSM LTE module (INT-GSM / INT-GSM LTE module connected to the control panel)
or ETHM-1 Plus module (INT-GSM / INT-GSM LTE module connected to the ETHM-1 Plus
module).
Reporting in case of INTEGRA 128-WRL control panel / by using the GSM
module
If the event codes are to be send by using the GSM module:
• As an external modem, the following module must be connected to the control panel
(the RS-232 ports of control panel and module must be connected):
- GSM-X / GSM-X LTE,
- GSM LT-2 with firmware 2.11 (or newer),
- GSM-4 with firmware 4.11 (or newer),
- GSM-5.
• If the GSM module is only connected to the control panel dialer terminals (TIP and
RING), the settings of the reporting via cellular data network will be ignored.
• The EXTERNAL MODEM and MODEM ISDN/GSM/ETHM options must be enabled in the
control panel (see: “Telephone options” p. 71).
1. Enable the REPORTING – GPRS option.
2. Determine whether the event codes will be sent to both monitoring stations or to one of
them only (STATION 1 OR 2 / STATION 1 / STATION 2 / STATION 1 AND 2).
3. Program the following for the monitoring station to which event codes are to be sent:
– reporting format in which the codes will be sent,
– server address,
– port number,
