60 Programming SATEL
Restore disables verif. – option for the 89. FINISHING EXIT DELAY zone type. If it is enabled,
the zone restore will disable verification of alarms in the partition. All alarms will be
unverified until the partition is armed again.
Disabled in arm state – option for the 91. DETECTOR MASK zone type. If the option is enabled
and the zone is violated when armed, the information on detector trouble (masking) will not
be stored into the event log (the event code will not be sent to the monitoring station).
4.3.7 Counters
The control panel makes it possible to program 16 different counters which determine the
operating mode of the counter zones (zone types 16-31). The counter parameters can be
programmed:
• using the keypad, in the service mode, by means of the COUNTERS function (ZONES
COUNTERS).
• using the DLOADX program, in the “Zones” window, “Counters” tab.
The following should be programmed for each counter:
Max. value – number of violations which, if exceeded, will trigger an alarm.
Counting time – the time in which violations are counted.
Counter type:
normal – all violations of counter group zones are counted,
omit recurs – skips violations of the same zone (the alarm will be triggered, if the number
of violations of different zones exceeds the maximum value).
If the counter skips repeats, the programmed Maximum counter value must be lower
than the number of zones in counter group.
4.3.8 Bypasses
You can define a group of zones for each of the zone types from 64 to 79:
• using the keypad, in the service mode, by means of the BYPASSES function (ZONES
BYPASSES).
• using the DLOADX program, in the “Zones” window, “Bypasses” tab.
Having assigned the zones to a group, define what reaction should be to violation of the
bypassing zone:
Bypass only – the zones belonging to the group will be bypassed for BYPASS TIME (see:
p. 52).
Bypass on/off – the zones belonging to the group will remain bypassed as long as the
bypassing zone is violated (they can be bypassed by the user).
In the LCD keypad, use the BYPASS ON/OFF option to make your selection. Option
disabled – see: BYPASS ONLY. Option enabled – see: BYPASS ON/OFF.
4.3.9 Groups of partitions
You can define up to 16 partition groups which will be controlled using the 80. ARMING,
81. DISARMING, 82. ARM/DISARM and 83. CLEARING ALARM type zones. The partition groups
can be defined:
• using the keypad, in the service mode, by means of the GROUPS function (ZONES
GROUPS).
• using the DLOADX program, in the “Zones” window, “Arm/Disarm Groups” tab.
4.3.10 Zone testing
Using the function available in the service mode menu in the keypad (ZONES TEST), you
can test the zones. Information on violation or tamper of the zone is displayed and signaled
