80 Programming SATEL
DLOADX connection
Address [Addr. D] – address of the computer with DLOADX program with which the control
panel is to communicate via the cellular data network (GPRS). The computer with
DLOADX program must have a public IP address. You can enter either the IP address or
the domain name.
Port [Port D] – number of the TCP port used for communication with the DLOADX program.
SMS [SMS DLOADX] – the control command which, if sent in the SMS message, will initiate
communication between the alarm control panel and the DLOADX program (modem /
GPRS).
GUARDX connection
Address [Addr. G] – address of the computer with GUARDX program with which the control
panel is to communicate via the cellular data network (GPRS). The computer with
GUARDX program must have a public IP address. You can enter either the IP address or
the domain name.
Port [Port G] – number of the TCP port used for communication with the GUARDX program.
SMS [SMS GUARDX] – the control command which, if sent in the SMS message, will initiate
communication between the alarm control panel and the GUARDX program (modem /
GPRS).
Advanced [Audio]
The GSM communicator sound settings are modifiable. In most cases, the factory default
settings are optimal for correct communication.
8. Programming the keypads
You can program the keypads:
• using the keypad, in the service mode, by means of the functions available in the LCD
KEYPADS submenu (STRUCTURE HARDWARE LCD KEYPADS) – having selected the
SETTINGS or NAMES function, choose the keypad,
• using the DLOADX program, in the “Structure” window, “Hardware” tab, after clicking on
the keypad name.
8.1 Keypad parameters and options
This section covers the INT-KLCD, INT-KLCDR, INT-KLCDK, INT-KLCDL,
INT-KLCDS and INT-KLFR keypads. Parameters and options for other keypads are
described in their respective dedicated manuals.
Shown in the square brackets are the names, as used in the keypads.
8.1.1 Keypad
Name – individual name of the LCD keypad (up to 16 characters).
Partitions managed by keypad [Partitions] – partitions which can be armed/disarmed or
alarm in which may be cancelled from the keypad. These functions are available to the
users having appropriate rights and access to these partitions.
Using the service code you can operate all partitions, irrespective of which partitions
are operated by the keypad.
Show alarms of partitions [Alarms] – the keypad can signal burglary alarms from selected
partitions.
