SATEL INTEGRA 55
6. EXIT – violation of the zone during exit delay countdown is equivalent to the partition exit.
7. DAY/NIGHT – if disarmed, the zone will signal violation acoustically in keypads and on
the 9. DAY ALARM, 12. SILENT ALARM and 116. INTERNAL SIREN outputs. When armed, the
zone acts as the 5. INSTANT zone.
8. EXTERIOR – a zone with alarm verification: zone violation will start counting the surveillance
time – if a second violation takes place during this time, an alarm will be triggered. If the
SURVEILLANCE TIME is not programmed (the value 0 is entered), the alarm will be generated
upon the first violation.
9. 24H TAMPER – permanently armed zone, intended for the tamper circuits. The zone
violation will additionally cause a trouble condition.
10. 24H VIBRATION – permanently armed zone, intended for working with vibration detectors.
If the partition includes the 10. 24H VIBRATION zone, starting the procedure of arming
from the LCD keypad will initiate a test of vibration detectors (the 39. TEST VIBRATION
DETECTORS output is activated and the countdown of time remained to the test end is
running).
11. 24H CASH MACHINE – permanently armed zone, intended for protection of a cash machine.
12. PANIC-
AUDIBLE – permanently armed zone, intended for operating the panic buttons.
13. PANIC-
SILENT – permanently armed zone, intended for operating the panic buttons.
Violating the zone will trigger a silent alarm.
14. MEDICAL – BUTTON
15. PERSONAL EMERGENCY
The zone types 14 and 15 trigger alarm signaled in the LCD keypads and on the 12. SILENT
ALARM
outputs. The names of zones and codes of events from these zones are consistent
with the Contact ID reporting format.
16...31 COUNTING C1...16 – the counting zones will signal an alarm when the number of
violations counted during a specified time period exceeds the set value (see: “Counters”
p. 60). Violations of the counting zones in armed mode can be signaled at the 9. DAY
ALARM, 12. SILENT ALARM and 116. INTERNAL SIREN outputs.
32. 24H FIRE
33. 24H FIRE – SMOKE
34. 24H FIRE – COMBUSTION
35. 24H FIRE – WATER FLOW (FIRE)
36. 24H FIRE – HEAT
37. 24H FIRE – PULL STATION
38. 24H FIRE – DUCT
39. 24H FIRE – FLAME
The zone types from 32 to 39 cause a fire alarm. The names of zones and codes of events
from these zones are consistent with the Contact ID reporting format. The fire zones (except
for 24H FIRE – BUTTON) can work with alarm verification.
40. 24H FIRE SUPERVISORY
41. 24H LOW WATER PRESSURE
42. 24H LOW CO2
43. 24H WATER VALVE DETECTOR
44. 24H LOW WATER LEVEL
45. 24H PUMP ACTIVATED
46. 24H PUMP FAILURE
