36 Programming SATEL
Configuration on control panel side
Configuration on computer side
Built-in 300 bps modem Analog modem
External analog modem
Analog modem
External ISDN modem
ISDN modem
GSM modem
External or built-in GSM modem
GSM modem
Table 4. Selecting control panel and computer modems.
Communication can be established in several ways (shown in parentheses is information
about requirements on the control panel side):
1. Connection initialized from the DLOADX program (built-in modem 300 bps or external
analog modem). This method makes it possible to establish connection with the control
panel from any location. Establishing connection by this method is possible, if the
computer telephone number has not been programmed in the control panel.
2. Connection initialized from the DLOADX program, but the control panel calls back and
sets up the connection (built-in 300 bps modem or external analog modem). The control
panel may only be remotely programmed from a specified locality.
3. Connection initialized by means of SMS (INTEGRA 128-WRL control panel or SATEL
GSM module operating as an external modem).
4. Connection initialized by the control panel (all configurations). The control panel may only
be remotely programmed from a specified locality. It can be applied if the system user
prefers that the remote programming cannot be carried out without his knowledge.
Connection initialized from the DLOADX program
Control panel settings:
• do not program the telephone number of modem connected to computer!
• if an external modem is connected to the control panel, enable the EXTERNAL MODEM
option,
• if a GSM or ISDN modem is connected to the control panel, enable the MODEM
ISDN/GSM/ETHM option,
• enable the ANSWERING – MODEM option [any modem] or the ANSWERING – ETHM/GSM
option [recommended for GSM or ISDN modem],
• define the number of rings after which the control panel will answer incoming calls (RINGS
BEFORE ANSWER
) [this does not apply to the GSM or ISDN modem],
• enable the DOUBLE CALL option if the control panel is to answer only after the second call
[this does not apply to the GSM or ISDN modem].
DLOADX program settings:
• program the telephone number of control panel,
• configure the modem communication parameters.
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Select in it the appropriate control panel modem.
A window will open in which information on the modem initialization will be displayed.
3. Click on the “Connect” button.
