7.09 Settings: GPS Settings
7.09 GPS Settings
(GPS MAP → MAIN MENU → Settings →
GPS settings)
Position Display Format (ie. grid reference
format)
• Use the joystick, moving left/right to select
from OSGB (Ordnance Survey GB); German
Grid; UTM; MGRS; GARS; CH1903/LV03
Swiss Grid; Swedish Grid RT90; French Grid
Lambert 2E; French Grid Lambert93; Irish
Grid ITM; Irish Grid IG; Pakistan MG; New
Zealand TM; Degrees decimal; Degrees,
minutes decimal; Degrees minutes, seconds
decimal; British Grid.
• Press Done or center press the joystick to
return to SETTINGS MENU.
OSGB grid references are given to 10 gures.
If you are working to 6-gure grid references,
set the last 2 digits of each number set to 0.
GPS Used as Heading at
The Active 10 has an electronic compass
(good when stationary) and a GPS compass
(good when in motion), and switches between
the two at a preset speed. In this setting you
are able to select the speed at which the GPS
compass overrides the electronic compass.
The GPS compass is more accurate the
faster you go.
• Use the joystick, moving left/right to select
from Never, then from 1 kph/0.5 mph to 16
kph/10 mph.
• Press Done or center press the joystick to
return to SETTINGS MENU.
Altitude Data Source
• Use the joystick, moving left/right to toggle
between Altitude from GPS and Altitude
from Maps.
Pressing the Default button restores the
following settings:
Position Display Format
OSGB
GPS Used as Heading at
2 kph / 1.2 mph / 1.08kn
Elevation Data
Altitude from maps/Altitude from GPS
• Elevation data is found on all map cards
(except Ordnance Survey where the
elevation data is taken from the base
mapping of the units).
• GPS elevation data is also available and is
accurate to ± 50m.
Figure 7.09
