Block F : Limit Values
If measurement values exceed their MIN/MAX limits, a
corresponding event message is output (L1... L3, H1...
H3).
Monitoring starts 10 s after start up.
F01 Value for I-MIN
Range: -10...200,0 % I Default: 5,0 % I
Reference: Nominal Feed Rate B 02.
F02 Event Class I-MIN L1
Range: WARNING 2
WARNING 1
IGNORE
ALARM
Default:
WARNING 2
F03 Value for I-MAX
Range: -10...200,0 % I Default: 120,0 % I
Reference: Nominal Feed Rate B 02.
F04 Event Class I-MAX H1
Range: WARNING 2
WARNING 1
IGNORE
ALARM
Default:
WARNING 2
F05 Value for Q-MIN
Range: -10...200.0 % Q Default: 20,0 % Q
Reference: Nominal Belt Load D 01
F06 Event Class Q-MIN L2
Range: WARNING 2
WARNING 1
IGNORE
ALARM
Default:
WARNING 2
F07 Value for Q-MAX
Range: -10...200,0 % Q Default: 120,0 % Q
Reference: Nominal Belt Load D 01
F08 Event Class Q-MAX H2
Range: WARNING 2
WARNING 1
IGNORE
ALARM
Default:
WARNING 2
F09 Value for V-MIN
Range: -10...200,0 % V Default: 5.0 % V
Reference: Nominal Speed B 05
F10 Event Class V-MIN L3
Range: WARNING 2
WARNING 1
IGNORE
ALARM
Default:
WARNING 2
F11 Value for V-MAX
Range: -10...200,0 % V Default: 120,0 % V
Reference: Nominal Speed B 05
0837
INTECONT PLUS VBW
Parameterization
BV-H2214 GB 57
