Block N : Scale Monitoring
N01 CPD Active
Range: NO
YES Default: NO
Starts speed-controlled delay element used to shift
belt load measurement to the point of material
discharge.
Prerequisites: Speed meter must be present and
active. No belt circuit sensor is
required.
N02 Platf.Dis.Length
Range: 0.00...50.00 %LB Default: 0.00 %LB
Input required only with CPD active
Length from mid platform to material discharge point
in % of total belt length LB.
The resolution is approx. 200.
N03 Belt Sensor Active
Range: NO
YES
Default: NO
Belt sensor and sensor area on conveyor belt are
designed to acquire belt slip and belt drift, and
synchronize the adaptive belt influence compensation
BIC.
N04 Source Sensor
Range: —
DI Default: DI (DI6)
Digital input for belt sensor. Can be checked using the
relevant service value.
Only DI6 can be used. If you select alternative “-”, BIC
and belt monitoring functions cannot be used.
N05 BIC Active
Range: NO
YES
Default: NO
Lets you start adaptive belt influence compensation
BIC.
To initialize BIC:
The dynamical tare portion is cleared upon power-up
or after changes to a parameter of the following list:
· Parameter N 05 “BIC Active”
·
Parameter B 04 “vs Charact. Val.”
·
Parameter D 06 “Belt Circuit Char”
Brief instructions:
1. N03 = YES, enter N 06... N 08.
2. Start setting program “LB: IMP/Belt”.
3. Activate BIC (N05 = YES).
4. Tare.
0837
INTECONT PLUS VBW
Parameterization
BV-H2214 GB 71
Transmission to third parties and reproduction of
this documentation are not permitted.
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
Technische
Redaktion PDE-RD
