N06 Sensor Length
Range: 0.01....400.00 cm Default: 8.20 cm
Length of sensor area in direction of belt travel.
See also Service value “Imp.S.”.
N07 Sensor Width
Range: 0.01...400.00 cm Default: 12.00 cm
Width of sensor area
N08 Sensor Offset
Range: -400.00....400.00 cmDefault: 0.00 cm
The offset lets you correct the zero point of the belt
run monitoring result.
However, the maximum display range is limited.
Therefore bigger corrections should be effected by
sensor shifting (see Commissioning chapter).
New display = old display - offset
N09 Belt Drift
Range: 0.01...400.00 cm Default: 3.00 cm
Limit value for admissible belt drift. If exceeded, event
message C4 “Belt Drift” is output and digital output
N15 “DO Slip Event” is set.
N10 Belt Drift Event C4
Range: WARNING 1
WARNING 2
Ignore
Alarm
Default: WARNING 1
(C04)
Cause of event: Belt leaves specified tolerance
range.
Action:
1. Clean head and tail pulleys.
2. Align belt.
Monitoring system can fail, too. So watch service
values of belt circuit sensor and remove fault, if any.
N11 Belt Skew
Range: 0.01...400.00 cm Default: 4.00 cm
Limit value for admissible belt skew. If exceeded,
event message C3 “Belt Skew” is output and digital
output N16 “DO Belt Skew” is set.
N12 Belt Skew Event C3
Range: WARNING 1
WARNING 2
Ignore
Alarm
Default: Alarm (C03)
Conveyor belt is too far off-centre. Feeder is no longer
operable.
Action: See Belt Drift event.
N13 Slip Limit
Range: 0.00...10.00 %LB Default: 2.00 %LB
Admissible variance of belt length in % of total belt
length.
Limit value exceeded, event message C8 “Slip Error”
is output and digital output N17 “DO Slip” is set.
0837
VBW INTECONT PLUS
Parameterization
BV-H2214 GB 72
