Schenck process Intecont Plus Belt Weigher - Parameter Block Q: Digital Outputs

N14 Slip Event C8
Range: WARNING 1
WARNING 2
IGNORE
ALARM
Default: WARNING 1
(C08)
Admissible limit value (N13) is exceeded.
N15 Do Belt Drift
Range: DO
__
Default: __
Digital output used to report belt drift.
N16 DO Belt Skew
Range: DO
__
Default: __
Digital output used to indicate belt skew event.
N17 DO Slip
Range: DO
__
Default: __
Digital output used to indicate belt slip event.
M18 Freeze BIC
Range: DI
__
Default: —
If digital input is set, current BIC values are frozen.
This helps to protect acquired values from falsification
upon heavily varying belt loads.
0837
INTECONT PLUS VBW
Parameterization
BV-H2214 GB 73
