Vehicles with auxiliary radiator
– Loosen hose clips -1- and -2- and remove coolant hoses.
Continued for all vehicles
– Detach electrical connectors -1, 2- from bracket, unplug con‐
nectors and move electrical wiring clear.
– Unscrew bolt -2-; remove screw-type clip.
– Loosen nuts -1, 3- and push to rear. (Illustration shows engine
removed.)
For vehicles with particulate filter
– Disconnect electrical connector from pressure differential
sender for particulate filter - G1037- -arrow-.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
1. Removing and installing the engine 15
