Vehicles with all-wheel drive
– Secure gearbox to engine.
– Screw in bolts -1- and -2- securing the holder of the bevel box
by hand.
– Note tightening sequence:
1 - Tighten screws -2-: 40 Nm.
2 - Tighten nuts -1-: 40 Nm.
Continued for all vehicles
– Install starter ⇒ Electrical system; Rep. gr. 27 ; Starter; Re‐
moving and installing starter .
– Guide engine/gearbox assembly into body.
– Initially screw in bolts -arrows- for engine mounting by hand
until they make contact.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
1. Removing and installing the engine 41
