♦ Retainer - T10375-
♦ Flange nut - 10531/4- from assembly tool - T10531-
♦ Puller hooks - T40274-
Removing
– Remove vibration damper ⇒ page 61 .
• Clamping pin - T10531/2- is inserted.
– Using extractor hook - T40274- , pull out seal -arrow-.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
1. Cylinder block (pulley end) 71
