– Unscrew the bolt -2-.
Note
The drive sprocket bolt has a left-hand thread.
– Detach drive sprocket -1- for toothed belt for coolant pump.
– Remove idler gear -1-.
– Remove bearing mounting -1-.
– Remove bolt -2- securing balance shaft (inlet side) and pull out
balance shaft.
Ateca 2017 ➤ , León 2013 ➤ , León ST 2013 ➤
4 cyl. petrol engine (1.8 l and 2.0 l with direct injection, 4 V, exhaust gas turbocharger, timing chain,
EA 888 III. Gen) - Edition 10.2018
4. Balancing shaft 89
