5.18
SEL-551 Relay Instruction Manual Date Code 20110408
Serial Port Communications and Commands
Command Explanations
=>SHO P <Enter>
PROTOCOL= SEL
SPEED = 2400 DATA_BITS= 8 PARITY= N STOP = 1
TIMEOUT= 15 AUTO = N RTS_CTS= N FAST_OP= N
=>SHO R <Enter>
Sequential Events Recorder trigger lists:
SER1 =51P1 51G1 51P1T 51G1T 50P1 50P2
SER2 =IN1 LB1 LB3 LB4 OUT1 OUT2 OUT3
SER3 =CF 79RS 79LO SV5T
=>SHO T <Enter>
Text Labels:
NLB1 =RECLOSER CLB1 =DISABLE SLB1 =ENABLE PLB1 =
NLB2 = CLB2 = SLB2 = PLB2 =
NLB3 =MANUAL TRIP CLB3 =RETURN SLB3 = PLB3 =TRIP
NLB4 =MANUAL CLOSE CLB4 =RETURN SLB4 = PLB4 =CLOSE
NLB5 = CLB5 = SLB5 = PLB5 =
NLB6 = CLB6 = SLB6 = PLB6 =
NLB7 = CLB7 = SLB7 = PLB7 =
NLB8 = CLB8 = SLB8 = PLB8 =
DP1_1 = DP1_0 =
DP2_1 =79 ENABLED DP2_0 =79 DISABLED
DP3_1 = DP3_0 =
DP4_1 =BREAKER CLOSED DP4_0 =BREAKER OPEN
DP5_1 = DP5_0 =
DP6_1 = DP6_0 =
DP7_1 = DP7_0 =
DP8_1 = DP8_0 =
79LL =SET RECLOSURES 79SL =RECLOSE COUNT
STA Command (Status)
The STA command displays the status report, showing the relay self-test
information.
To view a status report, enter the command:
=>STA N <Enter>
where:
N = a number (N = 1, 2, 3, ...) that specifies the number of
times to repetitively display the status report. If no
number is entered after the STA command, the relay
displays the status report only once.
