Sel 551 - Table 5.6 SEL-551 Relay Word and Its Correspondence to TAR Command and Front-Panel Leds

5.21
Date Code 20110408 Instruction Manual SEL-551 Relay
Serial Port Communications and Commands
Command Explanations
Command TAR 9 10 is executed in the following example:
=>TAR 9 10 <Enter>
79RS 79CY 79LO SH0 SH1 SH2 SH3 SH4
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
79RS 79CY 79LO SH0 SH1 SH2 SH3 SH4
0 0 1 0 0 1 0 0
0 0 1 0 0 1 0 0
Note that Relay Word bits row 9 is repeated 10 times on the computer display.
In this example, the reclosing relay is in the Lockout State (79LO = logical 1),
and the shot is at shot = 2 (SH2 = logical 1). Correspondingly, the remapped
front-panel targets have the A LED illuminated (corresponding to Relay Word
Bit 79LO in row 9) and the N LED illuminated (corresponding to Relay Word
Bit SH2 in row 9).
TIM Command (Time)
TIM displays the relay clock. To set the clock, type TIM and the desired
setting, then press <Enter>. Separate the hours, minutes, and seconds with
colons, semicolons, spaces, commas, or slashes. To set the clock to 23:30:00,
enter:
=>TIM 23:30:00 <Enter>
23:30:00
=>
Table 5.6 SEL-551 Relay Word and Its Correspondence to TAR Command and Front-Panel LEDs
TAR 0
(Front-
Panel
LEDs)
EN INST A B C N RS LO
TAR 1
51P1 51P2 51N1 51G1 51P1T 51P2T 51N1T 51G1T
TAR 2
51Q1 51Q2 51Q1T 51Q2T 50P1 50P2 50P3 50P4
TAR 3
50P5 50P6 50N1 50N2 50G1 50G2 50Q1 50Q2
TAR 4
50A 50B 50C IN1 IN2 OC CC CF
TAR 5
LB1 LB2 LB3 LB4 LB5 LB6 LB7 LB8
TAR 6
RB1 RB2 RB3 RB4 RB5 RB6 RB7 RB8
TAR 7
SV1 SV2 SV3 SV4 SV5 SV6 SV7 SV8
TAR 8
SV9 SV10 SV11 SV12 SV13 SV14 *
a
*
a
TAR 9
79RS 79CY 79LO SH0 SH1 SH2 SH3 SH4
TAR 10
TRIP CLOSE 51P1R 51P2R 51N1R 51G1R 51Q1R 51Q2R
TAR 11
SV5T SV6T SV7T SV8T SV9T SV10T SV11T SV12T
TAR 12
SV13T SV14T *
a
ALARM OUT1 OUT2 OUT3 OUT4
TAR 13
PDEM NDEM GDEM QDEM TRGTR *
a
*
a
*
a
TAR 14
*
a
*
a
*
a
*
a
*
a
*
a
*
a
*
a
a
Reserved for future use.
