CASCII Command—SEL-551
CASCII Command—SEL-551
Display the SEL-551 Compressed ASCII configuration message by sending:
CAS <CR>
The SEL-551 sends:
<STX>
"CAS",5,"01A8"<CR>
"CST",1,"01B7"<CR>
"23H","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","IA","IB","IC",
"IN","MOF","+5V_PS","+5V_REG"," 5V_REG","+10V_PS"," 10V_PS","VBAT",
"TEMP","RAM","ROM","CR_RAM","EEPROM","2738"<CR>
"1D","I","I","I","I","I","I","I","9S","9S","9S","9S","9S","9S","9S","9S","9S","9S",
“9S","9S","9S","9S","9S","9S","15B4"<CR>
"CHI",1,"01A1"<CR>
"12H","REC_NUM","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC",
"EVENT","SHOT","CURR","TARGETS","1654"<CR>
"20D","I","I","I","I","I","I","I","I","6S","I","I","22S","0A70"<CR>
"CEV",1,"01AB"<CR>
"7H","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","0BB9"<CR>
"1D","I","I","I","I","I","I","I","05F4"<CR>
"7H","IA","IB","IC","IN","IG","TRIG","RLY_BITS","0A85"<CR>
"60D","F","F","F","F","F","1S","45S","06C8"<CR>
"CEV L",1,"0217"<CR>
"7H","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","0BB9"<CR>
"1D","I","I","I","I","I","I","I","05F4"<CR>
"7H","IA","IB","IC","IN","IG","TRIG","RLY_BITS","0A85"<CR>
"120D","F","F","F","F","F","1S","45S","06F5"<CR>
"CEV R",1,"021D"<CR>
"7H","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","0BB9"<CR>
"1D","I","I","I","I","I","I","I","05F4"<CR>
"7H","IA","IB","IC","IN","IG","TRIG","RLY_BITS","0A85"<CR>
"256D","F","F","F","F","F","1S","45S","06FF"<CR>
<ETX>
CSTATUS Command—SEL-551
Display status data in Compressed ASCII format by sending:
CST <CR>
The SEL-551 sends:
<STX>"MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","IA","IB","IC",
"IN","MOF","+5V_PS","+5V_REG","-5V_REG","+10V_PS","-10V_PS",
"VBAT","TEMP","RAM","ROM","CR_RAM","EEPROM","261B" <CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"xxxx","xxxx","xxxx","xxxx","xxxx","xxxx",
"xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"
<CR><ETX>
where:
xxxx = the data values corresponding to the first line labels
yyyy = the 4-byte hex ASCII representation of the checksum
