7.7
Date Code 20110408 Instruction Manual SEL-551 Relay
Standard Event Reports and SER
Standard 15-Cycle Event Reports
79
CF, 79RS, . Reclosing relay nonexistent
79CY, 79LO F Close failure condition CF asserts for only 1/8 cycle
R Reclosing relay in Reset State (79RS)
C Reclosing relay in Reclose Cycle State (79CY)
L Reclosing relay in Lockout State (79LO)
Shot
SH0, SH1, SH2 . Reclosing relay nonexistent
SH3, SH4 0 shot = 0 (SH0)
1 shot = 1 (SH1)
2 shot = 2 (SH2)
3 shot = 3 (SH3)
4 shot = 4 (SH4)
Lcl 12
LB1, LB2 1 Local bit LB1 asserted
2 Local bit LB2 asserted
b Both LB1 and LB2 asserted
Lcl 34
LB3, LB4 3 Local bit LB3 asserted
4 Local bit LB4 asserted
b Both LB3 and LB4 asserted
Lcl 56
LB5, LB6 5 Local bit LB5 asserted
6 Local bit LB6 asserted
b Both LB5 and LB6 asserted
Lcl 78
LB7, LB8 7 Local bit LB7 asserted
8 Local bit LB8 asserted
b Both LB7 and LB8 asserted
Rem 12
RB1, RB2 1 Remote bit RB1 asserted
2 Remote bit RB2 asserted
b Both RB1 and RB2 asserted
Rem 34
RB3, RB4 3 Remote bit RB3 asserted
4 Remote bit RB4 asserted
b Both RB3 and RB4 asserted
Rem 56
RB5, RB6 5 Remote bit RB5 asserted
6 Remote bit RB6 asserted
b Both RB5 and RB6 asserted
Rem 78
RB7, RB8 7 Remote bit RB7 asserted
8 Remote bit RB8 asserted
b Both RB7 and RB8 asserted
Rem OC
OC, CC o OPEN command executed
c CLOSE command executed
SELogic Var 12
SV1, SV2 1 SELOGIC Variable SV1 asserted
2SEL
OGIC Variable SV2 asserted
b Both SV1 and SV2 asserted
Table 7.3 Other Standard Event Report Columns (Sheet 2 of 3)
Column Heading
Corresponding Elements
(Relay Word Bits)
Symbol Definition
