5
Startup
Startup procedure
Operating Instructions – MOVIDRIVE
®
modular
156
5.4 Startup procedure
The application inverters are taken into operation using the MOVISUITE
®
engineering
software from SEW‑EURODRIVE.
15643252491
The startup is functionally divided into segments. The following steps illustrate in ex-
emplary fashion the startup procedure for an application inverter.
Drive train seg-
ment
Drive train Configuring drive trains.
Interfaces seg-
ment
Default Basic settings of the installed interfaces
• EtherCAT
®
• Standard I/O
• Encoder 1
Optional Basic settings of the options
• Fieldbus
• I/O card
• Encoder 2
• MOVISAFE
®
CS..
Functions segment
Inputs/outputs
• Standard I/O
• I/O card DI/DO
• I/O card AI/AO
Setpoints
• Basic settings
• PO data
• Setpoint buffer
• Fixed setpoints
• Control word 1–3
24748536/EN – 11/2017
