SEW-Eurodrive MOVIDRIVE MDA90A-0160-503-X-S00

8
Technical Data
General technical data
Operating Instructions – MOVIDRIVE
®
modular
212
8.2 General technical data
The following tables lists the technical data for all MOVIDRIVE
®
modular application
inverters independent of
• Type
• Design
• Size
• Power rating
MOVIDRIVE
®
modular
Interference immunity Meets EN61800-3; 2. Environment
Interference emission Limit value category C2 to EN61800‑3
Ambient temperature ϑ
amb
0°C to +45°C without derating
Type of cooling Increased air cooling due to installed, speed-controlled fan.
Environmental conditions
Climatic requirements
• Extended storage:
EN60721-3-1 class 1K2 temperature -25°C to +70°C
• Transportation:
EN60721-3-2 class 2K3 temperature -25°C to +70°C
• Operation (fixed installation, weatherproof):
EN60721-3-3 class 3K3 temperature 0°C to +45°C
Chemically active substances
• Extended storage:
EN60721-3-1 class 1C2
• Transportation:
EN60721-3-2 class 2C2
• Operation (fixed installation, weatherproof):
EN60721-3-3 class 3C2
Mechanically active substances
• Extended storage:
EN60721-3-1 class 1S1
• Transportation:
EN60721-3-1 class 2S1
• Operation (fixed installation, weatherproof):
EN60721-3-3 class 3S1
Vibration testing
• 3M5 according to EN60721-3-3
• 5M1 according to EN60721-3-5
Degree of protection according to EN60529
Power supply modules
MDP90A-0100-... – MDP90A-0250-...
IP20
Power supply modules
MDP90A-0500-... and larger
IP10
Axis modules
MDA90A-0020-... – MDA90A-0480-...
MDD90A-0020-... – MDD90A-0080-...
IP20
Axis modules
MDA90A-0640-... – MDA90A-1800-...
IP10, optional IP20
Pollution class 2 according to IEC60664-1
Overvoltage category III according to IEC60664-1
Installation altitude
Up to h ≤ 1000m without restrictions.
The following restrictions apply to heights ≥ 1000 m:
• From 1000 m to max. 3800 m: I
N
reduction by 1% per 100m
• From 2000 m to max. 3800 m: To maintain protective separation and the air gaps and
creepage distances according to EN61800‑5‑1, you have to connect an overvoltage pro-
tection device in order to reduce the overvoltages from category III to category II.
24748536/EN – 11/2017
