SEW-Eurodrive MOVIDRIVE MDA90A-0160-503-X-S00

6
Operation
Axis module fault
Operating Instructions – MOVIDRIVE
®
modular
197
Subfault: 33.10
Description: Boot timeout
Response: Output stage inhibit
System state: Fault ackn.with CPU reset
Cause Measure
Timeout during system boot Contact the SEW-EURODRIVE Service.
Subfault: 33.11
Description: Hardware compatibility error
Response: Output stage inhibit
Cause Measure
Firmware does not match device Contact the SEW-EURODRIVE Service.
Subfault: 33.12
Description: Memory module plugged
Response: Output stage inhibit
System state: Fault ackn.with CPU reset
Cause Measure
A plugged in memory module was detected during device start.
The setting for the device parameter source is set to "Internal
memory".
– Switch off device. Remove the memory module and restart
the device.
– Change the parameter non-volatile memory source to "Arbit-
rary" or "Replaceable memory module". Switch device off and
on again.
Subfault: 33.13
Description: Memory module removed
Response: Output stage inhibit
System state: Fault ackn.with CPU reset
Cause Measure
The device was started without memory module. The setting
for the device parameter source is set to "Replaceable memory
module".
Switch off device. Insert the memory module and restart the
device.
Replaceable memory module removed during ongoing opera-
tion
Change parameter "Non-volatile memory source" to "Internal
memory". Switch the device off and on again.
6.5.28 Error 34 Process data configuration
Subfault: 34.1
Description: Changed process data configuration
Response: Application stop + output stage inhibit
Cause Measure
Process data configuration changed during active process data
operation
– Stop the process data and make your changes. Then start
the process data again.
– Perform a reset. Doing so will stop the process data, apply
the changes, and restart the process data.
6.5.29 Error 35 Function activation
Subfault: 35.1
Description: Invalid TAN
Response: Emergency stop + output stage inhibit
Cause Measure
Incorrect TAN entered Enter TAN again.
The TAN was not created for this device. Check TAN.
When using a double axis, the TAN was generated for the
wrong subaddress in the device.
Enter a TAN for the assigned subaddress.
Subfault: 35.2
Description: Application requires a higher license
Response: Emergency stop + output stage inhibit
Cause Measure
Activated application module requires higher license. Enter a TAN for higher application activation.
24748536/EN – 11/2017
