4.5.7 Installing touch guards

All modules of the application inverter are equipped with touch guards [1] and the

outer modules of the axis system have closing covers [2], see the following figure. If

the axis system contains a master module, the closing cover [2] only needs to be at-

tached at the last module in the axis system.

Axis system with master module

[2]

[1]

20918974091

24748536/EN – 11/2017
