Operation
Axis module fault
Operating Instructions – MOVIDRIVE
®
modular
201
Subfault: 50.4
Description: Option card timeout error
Response: Output stage inhibit
Cause Measure
Option card signals timeout error on SPI bus Check the card slot and installation and correct if necessary.
– Check for EMC-compliant installation.
– Restart device.
Subfault: 50.5
Description: Watchdog error of option card
Response: Output stage inhibit
Cause Measure
Micro controller of the option card signals a watchdog error. Check the card slot and installation and correct if necessary.
– Check for EMC-compliant installation.
– Restart device.
Subfault: 50.6
Description: Ready signal timeout
Response: Output stage inhibit
Cause Measure
The card has booted but cyclic communication is not possible. Check the card slot and installation and correct if necessary.
– Check for EMC-compliant installation.
– Restart device.
Subfault: 50.7
Description: Frame error of option card
Response: Output stage inhibit
Cause Measure
Faulty communication between option card and basic unit –
6.5.35 Error 51 Analog processing
Subfault: 51.1
Description: Analog current input 4 mA limit
Response: Warning with self reset
Cause Measure
Input current below 4 mA Check input current.
6.5.36 Error 52 Explosion protection category 2 function
Subfault: 52.1
Description: Startup fault
Response: Output stage inhibit
Cause Measure
No valid startup available Perform startup.
Subfault: 52.2
Description: Illegal system function
Response: Output stage inhibit
Cause Measure
Illegal system function activated
Subfault: 52.3
Description: Inverter too large
Response: Output stage inhibit
Cause Measure
Ratio of inverter current and nominal motor current too large
Subfault: 52.4
Description: Parameterization of current limit characteristic
Response: Output stage inhibit
Cause Measure
Error while setting parameters for current limit characteristic.
