Technical Data
Technical data of the cards
Operating Instructions – MOVIDRIVE
®
modular
234
8.7.2 CES11A multi-encoder card
Voltage supply
The multi-encoder card is supplied by the basic device.
Technical data of encoder supply
Terminal designation Specification
Part number 28229479
Power consumption
Nominal power loss 24V 0.8 W
Maximum power consumption 24V (card including
encoder supply)
12.8 W
Encoder supply
12 V X17:15 DC 12 V ± 10%
24 V X17:13 DC 24 V -10%, +20% according to EN61131
Nominal output current 12V or 24V 500mA
Peak output current I
max
for 150μs 1000 mA
Capacitive load < 220 μF
Inductive load < 500 μH
Short-circuit protection of 12V supply Yes, but a permanent short circuit is not permitted.
Short-circuit protection of 24V supply Yes, but a permanent short circuit is not permitted.
Evaluable temperature sensor TF / TH / KTY84-130 / PT1000
Encoder connection
Encoder connection Specification
Connection on encoder card end 15-pin socket
Maximum encoder cable length - HTL encoder ES7C and EG7C: 300 m
- Standard HTL encoder: 200 m
- Other encoders: 100 m
