8.9.3 Line filter
Line filters are used to suppress interference emission on the line side of inverters.
UL and cUL approval
The listed line filters have cRUus approvals independent of the application inverter.
Technical data
Line filter NF0420-513 NF0420-523
Part number 17983789 17983797
Nominal line voltage V
N
Maximum 3 × AC 500 V, 50/60 Hz
Nominal current I
N
42 A
Nominal power loss 30 W 37 W
Ambient temperature ϑ
amb
0 °C to 45 °C
Terminal contacts L1/L2/L3 - L1'/L2'/L3' 2.5 – 16mm
2
Tightening torque L1/L2/L3 - L1'/L2'/L3' 2 – 4Nm 2 – 2.3 Nm
PE terminal contact M6
Tightening torque PE 6 Nm
Degree of protection IP20 according to EN60529
Weight 3 kg 4.5 kg
Line filter NF0910-523 NF1800-523
Part number 17987504 17987865
Nominal line voltage V
N
Maximum 3 × AC 500 V, 50/60 Hz
Nominal current I
N
91 A 180 A
Nominal power loss 51.5 W 89 W
Ambient temperature ϑ
amb
0 °C to 45 °C
Terminal contacts L1/L2/L3 - L1'/L2'/L3' 25 – 50mm
2
16 – 120mm
2
Tightening torque L1/L2/L3 - L1'/L2'/L3' 6 – 8 Nm 12 – 20 Nm
PE terminal contact M8 M10
Tightening torque PE 12 Nm 23 Nm
Degree of protection IP20 according to EN60529
Weight 5 kg 9 kg
Assignment to an inverter
Line filter NF0420-513 NF0420-523
Assignment to MDP90A- 0100, 0250
Line filter NF0910-523 NF1800-523
Assignment to MDP90A- 0500 0750
