3
Unit structure, axis system structure
Unit structure of the MDP power supply module
Operating Instructions – MOVIDRIVE
®
modular
32
3.4 Unit structure of the MDP power supply module
WARNING
Some of the modules shown in this chapter are depicted without touch guards.
Touch guards secure the live parts such as DC link, line connections and braking
resistor connections.
Uncovered power connections.
Severe or fatal injuries from electric shock.
• Never start up the application inverter without installed closed touch guards.
3.4.1 MDP90A-0100-.. (size 1)
24V
X5
+UZ
X4
-UZ
-UZ +UZ
GND
X7
X30 OUTX30 IN
BA C
[7]
[8]
[9]
[12]
[13]
[2]
[3]
[4]
[5]
[6]
[10]
[1]
X1 X3
[11]
1
2
3
4
18014411422564235
A: View from top B: View from front C: View from bottom
[1] Terminal screw for TN/TT systems [5] 7-segment display [12] X3: Braking resistor connection
[2] X7: Temperature monitoring brak-
ing resistor
[6] Standby display (Power) [13] X1: Line connection
[3] X30 OUT: System bus [7] X5: Connection +24V supply voltage
[4] X30 IN: System bus [8] PE connection
[9] X4: DC link connection
[10] PE connection housing
[11] Shield terminal
